Shelf Pin Jig and Hinge Jig Two-In-One, Self-Contained Clamping Function All Metal Shelf Pin Drilling Jig with 1/4" and 5Mm Drill Bits, Shelf Jig and Cabinet Hardware Jig Tool Drill Guide
Description Item model number AM1-CB-RUI Item dimensions L x W x H 9 x 4 x 1 inches Product Dimensions 9 x 4 x 1 inches; 1.48 Pounds Material Aluminum Country of Origin China Finish Type Titanium Aluminum Nitride Tool Flute Type Straight【2-in-1】 This tool is a combination of shelf pin jig and hinge jig functions. One tool can help you finish the whole cabinet DIY. 【Cost-effective】This shelf pin jig comes with two sizes of hardened steel drill bits: 1/4"(6mm) and 5mm. Meets all your shelf pin hole size requirements at once. A stop collar is also included. 【Precise And Efficient】This shelf pin jig can accurately drill seven 5mm or 1/4" (6mm) shelf pin holes at 1-1/4 inch distance in one quick pass. And the included Positioning Pin helps you to continue drilling more shelf pin holes. 37/50/64mm edge distance can help you set up all different shelf installion edge distance. 【All-in-one Hinge Drilling Jig】Our cabinet hinge drilling templates are for the most common concealed hinges in the United States. The distance from the 35mm hole to the wood panel edge is optional 3-6mm.Including hinge screws 48*6 and 45*9.5mm. 【Widely Used】All-metal shelf pin and hinge jig made of aluminum alloy material with friction-resistant surface. Multi-functional and multiple mounting size options are designed to already meet your common shelf pin hole and hinge installation. Perfect for DIY, woodworking and home improvement.
Product Description
37/50/64mm Offset
37/50/64mm edge distance can help you set up all different shelf installion edge distance.
32mm Hole Spacing System
Standard 32mm hole distance is perfect for shelf pin hole drilling, hinges and drawer slides.
All-in-one Hinge Drilling Jig
The distance from the 35mm hole to the wood panel edge is optional 3-6mm
Cost-effective
This shelf pin jig comes with two sizes of hardened steel drill bits: 1/4"(6mm) and 5mm. Meets all your shelf pin hole size requirements at once.
INSTRUCTIONS FOR USE
Does this shelf pin jig with 32mm hole spacing convert to imperial 1-1/4 inch exact equivalents?
The description of our conversion to imperial units on the page is for the convenience of those who are used to using imperial units; the converted values are approximately, not exactly, equal. Ultimately, the values in metric units will prevail.
Which is the main feature of this fixture?
This jig is our main focus for both drilling holes for shelf pins and for mounting concealed hinges.
When installing hinges on this jig you can only mark the holes and then drill them, will this affect the accuracy?
We have tested this jig over and over again and the hinge holes punched by this jig are just as accurate as those punched by other Hinge Hole Jigs that can punch hinge holes directly on the jig. So please don't worry about the accuracy.
